Ethylene in the
Greenhouse:
Symptoms, Detection
& Prevention
W. Roland Leatherwood and Neil S. Mattson
Department of Horticulture Cornell University
Ethylene, a small colorless, odorless gas composed of two carbon and
four hydrogen atoms (C2H4), is responsible for
both beneficial and undesirable effects in greenhouse crops. It can
prevent flowering, shorten internode length, increase branching, initiate
fruit ripening, trigger leaf and flower senescence and abscission,
cause leaf chlorosis (yellowing), and improve adventitious rooting.
Some crops are relatively insensitive to ethylene while others are
very sensitive. For example, Poinsettia shows little change after
a 24 hour 1 ppm ethylene exposure, yet Cuphea hyssopifolia abscises
all flowers after a 24 hour 0.01 ppm exposure. There are many potential
sources of unwanted ethylene such as ripening fruit, decomposing organic
matter, and exhaust from furnaces and vehicles. Because several factors
can simultaneously impact a plant’s response to ethylene, it
is easy to see why assessing a potential ethylene problem can be tricky.
Some symptoms of exposure can be transient, while others show up long
after the ethylene exposure has occurred, still other responses show
up only after long-term exposure. To help you eliminate ethylene related
crop delays and losses from your operation, this webpage details what
short term and chronic low concentration ethylene exposure looks like,
how to detect ethylene, track down the source, and fix the problem.
What does ethylene damage look like?
A plant's response to ethylene can vary with temperature, ethylene concentration and duration of exposure. Plant responses to acute or high concentration (> 0.1 ppm), exposures are well described and studied. Many growers can readily identify these symptoms. Brief exposures may occur due to events such as shipping plants in a tightly sealed container or one-time exposure to vehicle exhaust while plants are in a loading zone. Short duration exposures at high concentrations result in flower and leaf abscission, chlorosis, and downward bent leaves that look wilted, but are turgid (epinasty) (Figure 1). Longer-term exposure to high concentrations of ethylene can result in stunted growth, deformed or chlorotic leaves, delayed flowering and plant death (senescence).
|
Figure 1: Effects of 8 hour (short term) 1
ppm (acute) ethylene exposure. Leaf and flower abscission on portulaca
(A) and cuphea (B), respectively. Leaf epinasty of tomato (C)
and snapdragon (D), exposed plant is on the left. |
However, it can be more difficult to recognize plant responses to low concentration
(< 0.05 ppm) exposures. Low concentration exposure to ethylene
over extended periods of time (referred to as chronic ethylene exposure)
can occur during greenhouse production such as when a furnace is malfunctioning
and generates ethylene inside the greenhouse. To develop a visual
diagnostic guide of chronic ethylene exposure, an experiment was conducted
at Cornell University. Thirty species of bedding and potted plants
were grown in separate greenhouses and were exposed to ethylene concentrations
of 0.00, 0.01 and 0.05 ppm ethylene every night for the last 6 weeks
of production. Some results of these experiments are presented below.
For many plant species responses to low concentration ethylene exposures are subtle and can be easily missed. For example, petunias exposed to 0.01 ppm ethylene for 24 hours, exhibit early senescence of pollen shedding flowers (Figure 2). Of course, as a grower you're not tracking the life span of individual flowers, but the effect in the greenhouse would be a noticeable and sudden loss of petunia flowers in one part of the greenhouse, typically close to a furnace. Similarly zonal geraniums exhibit stipule yellowing after 48 hours when exposed to 0.01 ppm ethylene for 24 hours (Figure 4), yet the flowers do not shatter as is seen at higher concentrations. Longer term exposures at these concentrations result in less flowering for begonia, impatiens and lobelia (Figure 7), and petunia internode elongation and flower size is reduced (Figure 2). The figures below illustrate plant responses to low concentrations of ethylene. Complete results are summarized in Table 1.
|
|
|
Figure
2. Effects of low concentration ethylene on petunia.
After several weeks of exposure, flower size (A) and internode
elongation (B) are reduced at 0.01 and 0.05 compared with control
(0.00 ppm ethylene). An indicator of brief low concentration ethylene
exposure is premature senescence of mature flowers (C) within
24 to 48 hours of exposure. |
|
|
Figure 3. Flower shattering/abscission in response
to ethylene at very low concentrations. Cuphea hyssopifolia after
less than 24 hours exposure. Flowers have abscised from both ethylene
treated plants. Because of its extreme sensitivity to ethylene
and easily observed response, Cuphea is an excellent indicator
plant for ethylene. |
|
Figure 4. Stipule yellowing on zonal geranium
inflorescences at the same flowering stage exposed to 0.01 ppm
ethylene for 48 hours (right side, arrow). The inflorescences
look otherwise normal but eventually the ethylene exposed flowers
senesce prematurely. At higher ethylene concentrations, zonal
geranium flowers shatter, but these less dramatic symptoms are
a good early indicator of ethylene's presence. |
|
Figure 5. Leaf curling (left) of verbena exposed
to 0.05 ppm ethylene for 24 hours. Unexposed plant is on the right.
Early and reversible responses such as this can serve as indicators
that ethylene is present and action should be taken before irreversible
damage occurs. |
|
Figure 6. Increased curling of fuchsia leaves
as ethylene concentrations increase. The white lines represent
the traced foreground edge of the right uppermost expanding leaf.
Note that the leaf tips begin curling first. Leaf curling will
reverse if the ethylene source is removed. |
|
Figure 7. Examples of the effects of long term,
six week, low concentration ethylene exposure on several species
of spring annuals. A) The height of pansies is reduced but flower
count and size stays consistent. B) Impatiens grow more compactly
while flower size and counts are reduced. Similar results are
seen with C) lobelia and D) begonia. E) Primula leaves lie closer
to the soil line but flowering appears unaffected. |
Table 1: Complete
listing of all species tested and their response to short term and long term
ethylene exposure. If the response
appears at only a specific concentration, that will appear in the
description.
|
Plant
|
Short Term Response
(After 72 hours)
|
Long Term Response
(After Several Weeks)
|
Bacopa ‘Calypso Jumbo
Lavender’
|
Slight leaf curling
|
Reduced overall growth, flower counts and
branching
|
Basil ‘Sweet Large Leaf’
|
No Change (N/C)
|
Increased branching
|
Begonia fibrous ‘Cocktail Gin’
|
N/C
|
Reduced height, overall growth, flower count
|
Calendula ‘Bon Bon Yellow’
|
N/C
|
Reduced height, overall growth
|
Calibrachoa ‘Callie Dark Blue’
|
N/C
|
Reduced height and overall growth, increased
branching
|
Coleus
‘Stained Glassworks Copper’
|
N/C
|
Increased branching
|
Cuphea ‘Allyson Heather’
|
Complete flower shattering after 24 hours at
0.01 and 0.05 ppm ethylene
|
Reduced flowering, increased branching
|
Dahlia ‘Carolina Orange’
|
N/C
|
Early flower senescence
|
Dianthus ‘Telstar Pink’
|
N/C
|
Reduced height, branching, overall growth
and flower counts
|
Fuchsia ‘Trailing Dark
Eyes’
|
Slight leaf curling which increases with
concentration
|
Reduced branching, overall growth, increased
height, flower counts
|
Zonal Geranium ‘Rumba Fire’
|
Yellowing of stipules after 48 hours at 0.01
and 0.05 ppm ethylene
|
Increased flower counts
|
Gerbera ‘Jaguar Formula Mix’
|
N/C
|
Leaves are flatter against the soil
|
Impatiens ‘Super Elfin XP White’
|
Slight leaf curling after 24 hours at 0.05
ppm ethylene
|
Reduced height, overall growth, flower size
and flower counts
|
Lobelia ‘Riviera Blue Splash’
|
N/C
|
Reduced height, overall growth and flower
counts
|
French Marigold ‘Crested Bonanza Mix’
|
N/C
|
N/C
|
New Guinea Impatiens ‘Sonic Deep Purple’
|
N/C
|
Reduced height, overall growth
|
Osteospermum ‘Asti Purple’
|
N/C
|
Reduced overall growth, increased branching
|
Pansy ‘Delta Formula Mix’
|
N/C
|
Reduced height
|
Hot Pepper ‘Long Red Thin Cayenne’
|
N/C
|
N/C
|
Petunia multiflora prostrate single ‘Saguna
Pastel Yellow’
|
Rapid senescence of open flowers 24 to 48
hours after exposure to 0.01 and 0.05 ppm ethylene
|
Reduced overall growth, flower size and
flower counts, increased height and branching
|
Portulaca ‘Yubi Summer Joy Apricot’
|
Some leaf abscission within 24 hours of
exposure to 0.05 ppm ethylene. Leaf abscission does not persist long term
|
Reduced height and increased branching.
|
Primula ‘Danova Select Mix’
|
N/C
|
Leaves are flatter against the soil
|
Rosemary ‘Arp’
|
N/C
|
Reduced branching
|
Sanvitalia ‘Sundance Yellow’
|
N/C
|
N/C
|
Snapdragon ‘Florini Amalia Yellow’
|
N/C
|
Reduced height & flower scent at 0.05
ppm ethylene
|
Tomato ‘Beefsteak’
|
Epinasty within 24 hours of exposure to 0.01
or 0.05 ppm ethylene
|
Reduced overall growth & height
|
Torenia ‘Clown Blue’
|
N/C
|
Reduced overall growth, height and flower
counts
|
Verbena ‘Lannai Dark Red’
|
Slight leaf curling 24 hours after exposure
to 0.05 ppm ethylene
|
Reduced height
|
|
|
|
Detecting ethylene
If you suspect ethylene is present, then the first thing to do is
verify that there is indeed a problem. One of the easiest ways of
detecting ethylene is by the use of indicator plants. These are plants
so sensitive that they respond dramatically even at concentrations
as low as 0.01 ppm. Cuphea and Tomato both make excellent indicator
plants. Cuphea will abscise all its flowers (Figure 2); and tomato
will bend its leaves downward as if they are wilted but they will
remain turgid (epinasty) when ethylene is present even in very low
concentrations. Such responses usually show up within 24 hours of
exposure, though lower greenhouse temperatures can slow the response.
Use indicator plants which have not previously been exposed to ethylene
and place them throughout the greenhouse including any areas where
you suspect ethylene is originating.
A second and more reliable method to detect ethylene is by sending
an air sample to a commercial lab or a university lab such as the
one at North Carolina State University Plant Disease and Insect Clinic.
Contact the lab directly to find out about the details of the program,
obtain the necessary instructions and materials for collecting an
air sample before sending one in. When taking samples to send for
testing, choose from areas where you suspect ethylene may be coming.
These could be inside, near a unit heater, or outside of the greenhouse,
near a loading dock. Also sample areas where there is no ethylene
problem, as a basis for comparison. Commercial kits for detecting
ethylene are also available, but are not sensitive enough to detect
low concentrations.
A second and more reliable method to detect ethylene is by sending
an air sample to a commercial lab or a university lab such as the
one at North Carolina State University Plant Disease and Insect Clinic.
Contact the lab directly to find out about the details of the program,
obtain the necessary instructions and materials for collecting an
air sample before sending one in. When taking samples to send for
testing, choose from areas where you suspect ethylene may be coming.
These could be inside, near a unit heater, or outside of the greenhouse,
near a loading dock. Also sample areas where there is no ethylene
problem, as a basis for comparison. Commercial kits for detecting
ethylene are also available, but are not sensitive enough to detect
low concentrations.
Finding the source
If you find that ethylene is present in your greenhouse, the next
step is to find the source. Ethylene can come from several sources,
such as ripening fruit, decomposing plant material, plant growth regulators
that release ethylene, and as a by-product of incomplete combustion.
One class of plant growth regulators (including Florel© and Pistill©)
works by producing low concentrations of ethylene when the active
ingredient breaks down. If applied near or onto sensitive species,
the same brief exposure, low concentration ethylene responses will
be seen. Florel's ethylene is largely dissipated within 72 hours.
The most common source of ethylene in a greenhouse is from combustion
of fuel. Any type of combustion whether an engine or a heater, can
give off ethylene. Loading docks near the greenhouse and heavy equipment
used inside the greenhouse can both be sources. Avoid using gasoline
or propane-powered equipment at times when the houses are not ventilated.
Of course the most common type of combustion in the greenhouse is
the heating system itself. A poorly operated or maintained heating
system can rapidly ruin a crop.
Historically, as fuel prices increase, so do reports of ethylene damage.
When fuel prices are low and greenhouses are not as tight or thoroughly
insulated, ethylene from existing sources is easily ventilated away
through leaks. But, when fuel is expensive growers tighten and insulate
houses, and ethylene from pre-existing sources builds up and becomes
a problem. So, ethylene that was not a problem before becomes a problem
when fuel becomes dear and the greenhouse is tightened.
Preventing ethylene damage
If you discover that you do have an ethylene problem, the easiest
and most immediate intervention is periodic ventilation of the greenhouse
with clean outside air. Of course this is only a short term fix, and
shouldn’t be considered a long term solution, particularly when
heating costs are high.
The best approach to stop ethylene damage is the time honored ounce
of prevention. Careful and regular attention to the plant growing
environment, shipping areas and post-harvest conditions can go a long
way. In any of these areas ethylene can be present. Be sure to keep
the potential sources mentioned above away from highly sensitive crops.
Pay special attention to when and where heavy equipment is used. If
heavy equipment is used near the greenhouse, be sure that the house
is well ventilated so that the exhaust can rapidly escape. Wherever
possible, seal off the house from loading docks or similar areas.
If growing areas cannot be sealed off from loading docks, consider
using battery operated equipment whenever possible. When designing
a new greenhouse, orient intake vents such that they face away from
areas where vehicles frequently operate.
By far the most frequent source of ethylene is a malfunctioning heating
system. Diligent heating system maintenance not only prevents ethylene
problems but also improves your system’s efficiency. Of all
the heating systems available, typically gas fired unit heaters require
the most attention in terms of ethylene. Key issues with unit heaters
are maintenance, distribution tubes, vent stacks, ventilation, and
fuel lines. An annual maintenance program should start with the heat
exchanger. Check the exchanger for cracks by operating the unit while
looking for light through seams and connections. Gas lines should
be checked for leaks by painting them with soapy water and looking
for bubbles. Vent stacks should be examined for blockages or leaks
between the seams. The stacks should be high enough so that there
is no risk of exhaust making its way back into the greenhouse. The
pilot light and orifice should also be inspected and cleaned. The
furnace flame normally burns light blue, if it is orange or yellow
combustion is incomplete and service is needed.
Outside of maintenance, the installation of gas fired unit heaters
must be done carefully to avoid problems from a heater that is capable
of operating perfectly well. A distribution tube should be installed
to mix the hot air coming from the heater with ambient air and distribute
it efficiently throughout the greenhouse. The mixing of hot air with
ambient air dilutes any potential source of ethylene and eliminates
temperature gradients. Distribution tubes are especially important
for unvented heaters which release the products of combustion into
the greenhouse. Unvented heaters are very popular when heating costs
are high because of their efficiency. When unvented heaters are used
it is critical to periodically check that they are firing correctly
and that adequate ventilation of outside air is available.
Air intake required for combustion (make-up air) is also important
for unit heaters. If the heater has an insufficient make-up air, oxygen
levels within the greenhouse can drop and pollutants can build up
quickly. Such a condition is not only dangerous to the crop but to
personnel as well. Generally, 1 square inch of vent cross-sectional
area per 2,000 Btu capacity is enough. You will find specific information
in the installation and operation manual for your furnace.
The key to preventing ethylene damage is being proactive. Ensure that
heaters and equipment are well maintained, and reduce plant exposure
to potential ethylene sources. Keep an eye on your plants for irregular
growth and if potential ethylene damage is suspected be ready to take
steps to identify the source of the problem and eliminate the cause.
Links:
Ethylene:
Sources, Symptoms and Prevention for Greenhouse crops - A detailed
guide to identifying and solving problems with ethylene in production
greenhouses.
Heating
Systems Maintenance Pays – A general guide to seasonal heating
system maintenance for both oil and gas systems.
Avoiding
Ethylene Problems. Runkle & Beudry. GPN 2006. Description
of common ethylene problems, sources and sampling technique.
Print resources:
Ethylene:
Agricultural Sources and Applications - Muhammad Arshad and William
T. Frankenberger. A detailed description of biological activity, history,
sources, applications, and biosynthesis. Additional chapters on application
of ethephon/florel in agriculture.
Acknowledgements:
This work was funded, in part, by a grant from the Fred C. Gloeckner
Foundation, Inc. Plant material was donated by C. Raker and Sons, Inc.
We also acknowledge the valuable cooperation of numerous New York growers
for sharing their insights on their own ethylene experiences.
|
